Dimensions:
Datasheet:
| Gear Ratio | Rated Voltage | No Load | Rated Load | Stall Extrapolation | L Size | Weight | ||||
| Speed | Current | Torque | Speed | Current | Torque | Current | ||||
| V | RPM | A | Kg.cm | RPM | A | Kg.cm | A | MM | G | |
| 4.4 | 6 | 2273 | 0.3 | 0.1 | 1864 | 1.6 | 0.6 | 8.5 | 18 | 85 |
| 9.6 | 6 | 1042 | 0.3 | 0.3 | 854 | 1.6 | 1.2 | 8.5 | 17.5 | |
| 21.3 | 6 | 469 | 0.3 | 0.6 | 385 | 1.6 | 2.8 | 8.5 | 19 | 87 |
| 35.5 | 6 | 282 | 0.3 | 1.1 | 231 | 1.6 | 4.6 | 8.5 | 21 | 92 |
| 46.8 | 6 | 214 | 0.3 | 1.4 | 175 | 1.6 | 6.1 | 8.5 | ||
| 78 | 6 | 128 | 0.3 | 2.3 | 105 | 1.6 | 10.1 | 8.5 | 23 | 95 |
| 103 | 6 | 97 | 0.3 | 3.1 | 80 | 1.6 | 13.4 | 8.5 | ||
| 171 | 6 | 58 | 0.3 | 5.1 | 48 | 1.6 | 22.2 | 8.5 | 25 | 97 |
| 226 | 6 | 44 | 0.3 | 6.8 | 36 | 1.6 | 25 | 8.5 | ||
| 378 | 6 | 26 | 0.3 | 11.3 | 22 | 1.6 | 8.5 | 27 | 100 | |
| 500 | 6 | 20 | 0.3 | 15 | 16 | 1.6 | 8.5 | |||
| 4.4 | 12 | 4545 | 0.4 | 0.3 | 3864 | 2.2 | 1.2 | 17 | 18 | 85 |
| 9.6 | 12 | 2083 | 0.4 | 0.6 | 1771 | 2.2 | 2.6 | 17 | 17.5 | |
| 21.3 | 12 | 939 | 0.4 | 1.3 | 798 | 2.2 | 5.8 | 17 | 19 | 87 |
| 35.5 | 12 | 563 | 0.4 | 2.1 | 479 | 2.2 | 9.6 | 17 | 21 | 92 |
| 46.8 | 12 | 427 | 0.4 | 2.8 | 363 | 2.2 | 12.6 | 17 | ||
| 78 | 12 | 256 | 0.4 | 4.7 | 218 | 2.2 | 21.1 | 17 | 23 | 95 |
| 103 | 12 | 194 | 0.4 | 6.2 | 165 | 2.2 | 27.8 | 17 | ||
| 171 | 12 | 117 | 0.4 | 10.3 | 99 | 2.2 | Banning block MAX 25KG | 17 | 25 | 97 |
| 226 | 12 | 88 | 0.4 | 13.6 | 75 | 2.2 | 17 | |||
| 378 | 12 | 53 | 0.4 | 15 | 45 | 2.2 | 17 | 27 | 100 | |
| 500 | 12 | 40 | 0.4 | 34 | 2.2 | 17 | ||||
| Office |
| Workshop |
| Machine & Testing Equipment |
*shockproof foam packing
*Suitable carton size
*stretch film and pallet packing
*DHL,EMS,UPS,Epacket,ocean shipping
*Sample order send out in 2 days.
*General Service:
*Quick Reply:All enquiry or email be replied in 12 hours, no delay for your business.
*Professional Team:Questions about products will be replied professionally, exactly, best advice to you.
*Short Lead time:Sample or small order sent in 7-15 days, bulk or customized order about 30 days.
*Payment Choice:T/T, Western Union,, L/C, etc, easy for your business.
*Before shipment:Take photos, send to customers for confirmation. Only confirmed, can be shipped out.
*Language Choice:Besides English, you can use your own language by email, then we can translate it.
*Customization Service:
Motor specification(no-load speed , voltage, torque , diameter, noise, life, testing) and shaft length can be tailor- made according to customer’s requirements.
